Minimum integration costs.
Greater reliability and energy efficiency.
Improvement of maintenance capacity, reduction of average repair time (MTTR).
Functional Safety Unit (FSU) Performance Level 3 (PLd).
Multiple robot control of up to 8 robots / 72 axes with synchronized movement between devices.
Advanced robot movement control (ARM) provides high productivity and trajectory planning.
Small and lightweight pendant with Windows® CE programming color touch screen with multiple window display possibilities.
Number of axis: 6
Maximum horizontal reach: 2,702 mm
Maximum vertical reach: 3,393 mm
Repeatability: ±0.2 mm
Axis L: +76°/-60°
Axis U: +90/-147
Axis R: ±210° (Motion range limited by spot harness)
Axis B: ±130° (Motion range limited by spot harness)
Axis T: ±210° (Motion range limited by spot harness)
Axis L: 115°/s
Axis U: 125°/s
Axis R: 182°/s
Axis B: 175°/s
Axis T: 265°/s
Arc welding , Spotwelding , Press tending , Palletising , Loading and unloading of parts , Machining , Handling of parts , Measurement , Assembly of parts , Laser cutting , Laser welding Nd-Yag , Glueing - Adhesive bonding , Stud welding , Plasma cutting , 3C Electronics , Advanced Manufacturing , Education , Milling cell
